yarp::rosmsg::std_msgs::ColorRGBA Class Reference

#include <yarp/rosmsg/std_msgs/ColorRGBA.h>

+ Inheritance diagram for yarp::rosmsg::std_msgs::ColorRGBA:

Public Types

typedef yarp::os::idl::BareStyle< yarp::rosmsg::std_msgs::ColorRGBA > rosStyle

typedef yarp::os::idl::BottleStyle< yarp::rosmsg::std_msgs::ColorRGBA > bottleStyle


Public Member Functions

 ColorRGBA ()

void clear ()

bool readBare (yarp::os::ConnectionReader &connection) override

bool readBottle (yarp::os::ConnectionReader &connection) override

bool read (yarp::os::ConnectionReader &connection) override
 Read this object from a network connection. More...

bool writeBare (yarp::os::ConnectionWriter &connection) const override

bool writeBottle (yarp::os::ConnectionWriter &connection) const override

bool write (yarp::os::ConnectionWriter &connection) const override
 Write this object to a network connection. More...

yarp::os::Type getType () const override

- Public Member Functions inherited from yarp::os::idl::WirePortable
virtual bool read (yarp::os::idl::WireReader &reader)

virtual bool write (const yarp::os::idl::WireWriter &writer) const

- Public Member Functions inherited from yarp::os::PortReader
virtual ~PortReader ()
 Destructor. More...

virtual Type getReadType () const

- Public Member Functions inherited from yarp::os::PortWriter
virtual ~PortWriter ()
 Destructor. More...

virtual void onCompletion () const
 This is called when the port has finished all writing operations. More...

virtual void onCommencement () const
 This is called when the port is about to begin writing operations. More...

virtual yarp::os::Type getWriteType () const


Public Attributes

yarp::conf::float32_t r

yarp::conf::float32_t g

yarp::conf::float32_t b

yarp::conf::float32_t a


Static Public Attributes

static constexpr const char * typeName = "std_msgs/ColorRGBA"

static constexpr const char * typeChecksum = "a29a96539573343b1310c73607334b00"

static constexpr const char * typeText


Additional Inherited Members

- Static Public Member Functions inherited from yarp::os::Portable
static bool copyPortable (const PortWriter &writer, PortReader &reader)
 Copy one portable to another, via writing and reading. More...


Detailed Description

Definition at line 32 of file ColorRGBA.h.

Member Typedef Documentation

◆ bottleStyle

typedef yarp::os::idl::BottleStyle<yarp::rosmsg::std_msgs::ColorRGBA> yarp::rosmsg::std_msgs::ColorRGBA::bottleStyle

Definition at line 162 of file ColorRGBA.h.

◆ rosStyle

typedef yarp::os::idl::BareStyle<yarp::rosmsg::std_msgs::ColorRGBA> yarp::rosmsg::std_msgs::ColorRGBA::rosStyle

Definition at line 161 of file ColorRGBA.h.

Constructor & Destructor Documentation

◆ ColorRGBA()

yarp::rosmsg::std_msgs::ColorRGBA::ColorRGBA ( )
inline

Definition at line 40 of file ColorRGBA.h.

Member Function Documentation

◆ clear()

void yarp::rosmsg::std_msgs::ColorRGBA::clear ( )
inline

Definition at line 48 of file ColorRGBA.h.

◆ getType()

yarp::os::Type yarp::rosmsg::std_msgs::ColorRGBA::getType ( ) const
inlineoverridevirtual

Reimplemented from yarp::os::Portable.

Definition at line 178 of file ColorRGBA.h.

◆ read()

bool yarp::rosmsg::std_msgs::ColorRGBA::read ( yarp::os::ConnectionReader &  reader)
inlineoverridevirtual

Read this object from a network connection.

Override this for your particular class.

Parameters
readeran interface to the network connection for reading
Returns
true iff the object is successfully read

Implements yarp::os::Portable.

Definition at line 104 of file ColorRGBA.h.

◆ readBare()

bool yarp::rosmsg::std_msgs::ColorRGBA::readBare ( yarp::os::ConnectionReader &  connection)
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 63 of file ColorRGBA.h.

◆ readBottle()

bool yarp::rosmsg::std_msgs::ColorRGBA::readBottle ( yarp::os::ConnectionReader &  connection)
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 80 of file ColorRGBA.h.

◆ write()

bool yarp::rosmsg::std_msgs::ColorRGBA::write ( yarp::os::ConnectionWriter &  writer) const
inlineoverridevirtual

Write this object to a network connection.

Override this for your particular class. Be aware that depending on the nature of the connections a port has, and what protocol they use, and how efficient the YARP implementation is, this method may be called once, twice, or many times, as the result of a single call to Port::write

Parameters
writeran interface to the network connection for writing
Returns
true iff the object is successfully written

Implements yarp::os::Portable.

Definition at line 153 of file ColorRGBA.h.

◆ writeBare()

bool yarp::rosmsg::std_msgs::ColorRGBA::writeBare ( yarp::os::ConnectionWriter &  connection) const
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 110 of file ColorRGBA.h.

◆ writeBottle()

bool yarp::rosmsg::std_msgs::ColorRGBA::writeBottle ( yarp::os::ConnectionWriter &  connection) const
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 127 of file ColorRGBA.h.

Member Data Documentation

◆ a

yarp::conf::float32_t yarp::rosmsg::std_msgs::ColorRGBA::a

Definition at line 38 of file ColorRGBA.h.

◆ b

yarp::conf::float32_t yarp::rosmsg::std_msgs::ColorRGBA::b

Definition at line 37 of file ColorRGBA.h.

◆ g

yarp::conf::float32_t yarp::rosmsg::std_msgs::ColorRGBA::g

Definition at line 36 of file ColorRGBA.h.

◆ r

yarp::conf::float32_t yarp::rosmsg::std_msgs::ColorRGBA::r

Definition at line 35 of file ColorRGBA.h.

◆ typeChecksum

constexpr const char* yarp::rosmsg::std_msgs::ColorRGBA::typeChecksum = "a29a96539573343b1310c73607334b00"
staticconstexpr

Definition at line 168 of file ColorRGBA.h.

◆ typeName

constexpr const char* yarp::rosmsg::std_msgs::ColorRGBA::typeName = "std_msgs/ColorRGBA"
staticconstexpr

Definition at line 165 of file ColorRGBA.h.

◆ typeText

constexpr const char* yarp::rosmsg::std_msgs::ColorRGBA::typeText
staticconstexpr
Initial value:
= "\
float32 r\n\
float32 g\n\
float32 b\n\
float32 a\n\
"

Definition at line 171 of file ColorRGBA.h.

The documentation for this class was generated from the following file:
